Flat Open Barrel Wire Terminal Lug

RC-SB-003

Description

Flat tongue electrical crimp terminal with open barrel and circular mounting hole, ultra-thin flat tab for limited installation gaps, suitable for connecting single or multi-strand wires to grounding and power terminals, customizable barrel ID and hole diameter.

Manufacturing Process

Copper sheet precision stamping → open barrel forming → tongue hole punching → deburring → tin electroplating

Material

T2 pure copper

Surface Treatment

Glossy tin plating

Features

Ultra-flat structure fits narrow mounting space, open barrel for fast wire insertion, excellent electrical conductivity, corrosion resistant coating for humid environments, complete size range covering thin to thick cables

Application

Machine control panels, inverters, charging piles, new energy devices, cabinet grounding connections, small internal motor wiring

Drawing
