Ultra Thin Straight Guide Pins

RC-PN-006

Description

Slender precision CNC turned straight guide pin with ultra-small diameter, thin cylindrical locating pin for tiny gap alignment and light-duty positioning assembly.

Manufacturing Process

Fine CNC Turning, Centerless Grinding, Surface Polishing

Material

SUS304/SUS316 Stainless Steel, High Carbon Steel

Surface Treatment

Passivation, Bright Polishing, Black Oxide, Hard Chrome Plating

Features

• Slim long thin shaft design, ultra-small outer diameter options
• Excellent dimensional consistency for batch production
• Stainless steel anti-corrosion material optional
• Super smooth surface to avoid assembly scratch
• Custom length & micro-diameter production supported

Application

Precision Molds, Electronic Connector Jigs, Optical Equipment, Small Automation Tools, Watch Hardware Parts
